基于改进YOLOv5s+DeepSORT的煤块行为异常识别

张旭辉; 闫建星; 张超; 万继成; 王利欣; 胡成军; 王力; 王东

doi:10.13272/j.issn.1671-251x.17915

基于改进YOLOv5s+DeepSORT的煤块行为异常识别

1.
西安科技大学机械工程学院, 陕西西安　710054
2.
中煤(天津)地下工程智能研究院, 天津　300121
3.
陕西煤业化工集团孙家岔龙华矿业有限公司, 陕西榆林　719314

基金项目: 国家自然科学基金项目（51834006）；陕西省重点研发计划项目（2018ZDCXL-GY-06-04）。

详细信息

作者简介:
张旭辉(1972—),男，陕西凤翔人，教授，博士，博士研究生导师，研究方向为煤矿机电设备智能检测与控制，E-mail：zhangxh@xust.edu.cn

通讯作者:
闫建星(1995—)，男，陕西榆林人，硕士研究生，研究方向为智能检测与控制，E-mail:yanjianxing2013@163.com

中图分类号: TD76
计量
- 文章访问数: 496
- HTML全文浏览量: 332
- PDF下载量: 92
出版历程
- 收稿日期: 2022-04-11
- 修回日期: 2022-06-09
- 网络出版日期: 2022-06-27
- 刊出日期: 2022-06-29

Coal block abnormal behavior identification based on improved YOLOv5s + DeepSORT

1.
College of Mechanical Engineering, Xi'an University of Science and Technology, Xi'an 710054, China
2.
China Coal (Tianjin) Underground Engineering Intelligence Research Institute, Tianjin 300121, China
3.
Sunjiacha Longhua Mining Co., Ltd., Shaanxi Coal Chemical Industry Group, Yulin 719314, China

摘要

摘要: 煤块检测方法主要包括传统图像检测方法和深度学习目标检测方法。传统图像检测方法检测精度不高、实时性较差、无法对堆煤进行准确判断；深度学习目标检测方法虽然可以实现实时检测，但没有对煤块的数量、滞留和堵塞状态进行识别，而且识别模型参数较多。针对上述问题，提出了一种基于改进YOLOv5s+DeepSORT的煤块行为异常识别方法。首先通过摄像头和巡检机器人采集煤矿综采工作面带式输送机上煤块视频图像，并制作数据集。然后利用MobileNetV3_YOLOv5s_AF−FPN模型进行煤块图像目标检测：通过MobileNetV3替换原始YOLOv5s主干特征提取网络，减少参数量，提高推理速度；将YOLOv5s中原有的特征金字塔网络改进为增强特征金字塔网络（AF−FPN），以提高YOLOv5s网络对多尺度煤块目标的检测性能。利用DeepSORT进行煤块多目标跟踪：将改进YOLOv5s模型检测后的煤块图像作为DeepSORT的输入进行多目标跟踪，利用DeepSORT对煤块进行状态估计、数据关联匹配和跟踪器参数更新，确定跟踪结果，并对连续跟踪的煤块进行ID编码，对当前帧的煤块数量进行计数。最后在目标跟踪器中取出连续跟踪的目标，设置距离阈值，判断其是否滞留；设置数量阈值，判断其是否堵塞，最终实现煤块滞留和堵塞行为异常识别。利用自建dkm_data2021数据集对基于改进YOLOv5s+DeepSORT的煤块行为异常识别方法的可靠性进行实验验证，结果表明：改进YOLOv5s模型相比YOLOv5s模型平均检测精度提高了1.45%，参数量减少了35.3%，推理加速了12.7%，平均漏检率降低了11.08%，平均误检率降低了11.54%；基于改进YOLOv5s+DeepSORT的煤块行为异常识别方法检测精度为80.1%，可准确识别煤块滞留、堵塞状态，验证了该方法的可靠性。
- 煤块识别 /
- 煤块目标检测 /
- 目标跟踪 /
- 异常行为识别 /
- 煤块特征提取 /
- 煤块滞留 /
- 煤块堵塞 /
- 深度学习
Abstract: Coal block detection methods mainly include traditional image detection methods and deep learning target detection methods. The traditional image detection method has low detection precision and poor real-time performance, and can not accurately determine the coal pile. Although the deep learning target detection method can achieve real-time detection, it does not identify the number, retention, and blockage of coal blocks. And there are many identification model parameters. To solve the above problems, a coal block abnormal behavior identification method based on improved YOLOv5s + DeepSORT is proposed. Firstly, video images of coal blocks on a belt conveyor in a fully mechanized coal mining face are collected by the camera and inspection robot, and data sets are made. Secondly, the MobileNetV3_YOLOv5s_AF-FPN model is used for detecting the coal image target. The original YOLOv5s backbone feature extraction network is replaced by MobileNetV3 to reduce the number of parameters and improve the reasoning speed. The original feature pyramid network in YOLOv5s is improved to AF-FPN to improve the detection performance of the YOLOv5s network for multi-scale coal targets. DeepSORT is used for multi-target tracking of coal blocks. The coal block image detected by the improved YOLOv5s is taken as the input of DeepSORT for multi-target tracking. DeepSORT is used to estimate the state of coal blocks, perform data association and matching, and update the tracker parameters to determine the tracking results. The continuously tracked coals are ID-coded, and the number of coals in the current frame is counted. Finally, the continuously tracked target is taken out from the target tracker, and a distance threshold is set. Whether the target is detained or not is determined. The quantity threshold is set to determine whether it is blocked. The identification of abnormal behavior of coal block retention and blocking state is finally realized. The reliability of the coal abnormal behavior identification method based on the improved YOLOv5s + DeepSORT is experimentally verified by using the self-built dkm_data2021 data set. The results show that compared with the YOLOv5s model, the average detection precision of the improved YOLOv5s model is improved by 1.45%, the parameter quantity is reduced by 35.3%, the reasoning is accelerated by 12.7%, the average missed detection rate is reduced by 11.08%, and the average false detection rate is reduced by 11.54%. The detection precision of coal block abnormal behavior identification method based on the improved YOLOv5s+DeepSORT is 80.1%, which can accurately identify the status of coal block retention and blockage. The result verifies the reliability of the method.
- coal block identification /
- coal block target detection /
- target tracking /
- abnormal behavior identification /
- coal block feature extraction /
- coal block retention /
- coal block blockage /
- deep learning

HTML全文

图 1 YOLOv5s网络结构

Figure 1. YOLOv5s network structure

下载: 全尺寸图片幻灯片

图 2 改进后的YOLOv5s网络结构

Figure 2. Improved YOLOv5s network structure

下载: 全尺寸图片幻灯片

图 3 Bneck网络结构

Figure 3. Bneck network structure

下载: 全尺寸图片幻灯片

图 4 MobileNetV3_YOLOv5s_AF−FPN网络结构

Figure 4. MobileNetV3_YOLOv5s_AF-FPN network structure

下载: 全尺寸图片幻灯片

图 5 AAM网络结构

Figure 5. AAM network structure

下载: 全尺寸图片幻灯片

图 6 FEM网络结构

Figure 6. FEM network structure

下载: 全尺寸图片幻灯片

图 7 煤块行为异常识别方法流程

Figure 7. Flow of coal block abnormal behavior identification method

下载: 全尺寸图片幻灯片

图 8 DeepSORT多目标跟踪算法流程

Figure 8. DeepSORT multi-target tracking algorithm flow

下载: 全尺寸图片幻灯片

图 9 YOLOv5s模型与MobileNetV3_YOLOv5s_AF−FPN模型的煤块检测效果对比

Figure 9. Comparison of coal detection effect of YOLOv5s model and MobileNetV3_YOLOv5s_AF-FPN model

下载: 全尺寸图片幻灯片

图 10 煤块正常跟踪

Figure 10. Coal block normal tracking

下载: 全尺寸图片幻灯片

图 12 煤块堵塞

Figure 12. Coal block blockage

下载: 全尺寸图片幻灯片

图 11 煤块滞留

Figure 11. Coal block retention

下载: 全尺寸图片幻灯片

表 1 MobileNetV3_Large结构

Table 1 MobileNetV3_Large structure

Input Shape	Operator	SE	AF	Stride
224²×3	Conv2d	−	HS	2
112²×16	Bneck,3×3	−	RE	1
112²×16	Bneck,3×3	−	RE	2
56²×24	Bneck,3×3	√	RE	1
56²×24	Bneck,3×3	√	RE	2
28²×40	Bneck,3×3	√	RE	1
28²×40	Bneck,3×3	−	RE	1
28²×40	Bneck,3×3	−	HS	2
14²×80	Bneck,3×3	−	HS	1
14²×80	Bneck,3×3	−	HS	1
14²×80	Bneck,3×3	−	HS	1
14²×80	Bneck,3×3	√	HS	1
14²×112	Bneck,3×3	√	HS	1
14²×112	Bneck,5×5	√	HS	1
7²×160	Bneck,5×5	√	HS	2
7²×160	Bneck,5×5	√	HS	1
7²×160	Conv2d,1×1	−	HS	1
7²×160	Pool, 7×7	−	−	1
1²×960	Conv2d,1×1	−	HS	1
1²×1280	Conv2d,1×1	−	−	1

下载: 导出CSV

表 2 特征提取网络实验对比

Table 2 Comparison of feature extraction network experiments

模型	召回率	平均精度	参数量/M	平均漏检率	平均误检率	推理时间/ms
YOLOv5s	0.785	0.821	7.09	0.334	0.026	18.9
MobileNetV3_ YOLOv5s	0.766	0.795	3.56	0.365	0.027	15.0

下载: 导出CSV

表 3 特征融合网络实验对比

Table 3 Comparison of feature fusion network experiments

模型	召回率	平均精度	参数量/M	平均漏检率	平均误检率	推理时间/ms
YOLOv5s	0.785	0.829	7.09	0.334	0.026	18.9
YOLOv5s_AF−FPN	0.824	0.870	8.12	0.365	0.027	15.0
MobileNetV3_YOLOv5s	0.766	0.795	3.56	0.365	0.027	15.0
MobileNetV3_YOLOv5s_AF−FPN	0.810	0.841	4.59	0.297	0.023	16.5

下载: 导出CSV

表 4 多目标跟踪结果对比

Table 4 Comparison of multi-target tracking results

模型	MOTA/%	MOTP/%	漏检数	误检数	推理速度/ （帧·s⁻¹）
YOLOv5s+DeepSORT	60.5	76.5	119	57	34
MobileNetV3_YOLOv5s_ AF−FPN+DeepSORT	63.4	80.1	95	42	40

下载: 导出CSV
