井下仰角钻孔测井系统设计

基金项目:

安徽省杰出青年基金项目（1108085J03）

详细信息

Design of underground elevation drilling logging system

School of Electrical and Information Engineering, Anhui University of Science and Technology, Huainan 232001, China

摘要: 针对传统的测井系统存在总线利用率低、数据传输速率低等问题，提出了一种井下仰角钻孔测井系统设计方案，着重论述了系统结构、网络拓扑和以 PIC18LF4680为核心的探管节点的软硬件设计。该系统应用文件管理控制芯片管理系统数据，实现了有缆和无缆2种测井方式。实际应用表明，该系统运行稳定，适用于生产矿井工况的测量。
- 煤田测井 /
- 仰角钻孔 /
- 网络拓扑 /
- 数据管理
Abstract: For problems of low bus utilization and low data transfer rate and so on existed in traditional logging system, a design scheme of underground elevation drilling logging system was proposed, and the system structure, network topology, and design of hardware and software of the probe node with PIC18LF4680 as core were described. The system uses file management control chip for data management, achieves two logging ways of having cable and non-cable. The practical application shows that the system is stable and is applicable for measurement of mine production conditions.
- coal logging system /
- elevation drilling /
- network topology /
- data management
