基于ArcGIS Engine的矿井巷道三维自动建模方法的研究与实现

基金项目:

全国百篇优秀博士论文专项资金项目资助(200348)

国家自然科学基金重点项目资助(50534050)

详细信息

Research of 3D Automatic Modeling Method of Mine Laneway Based on ArcGIS Engine and Its Implementatio

1.
School of Environment Science and Spatial Informatics of CUMT.,Xuzhou 221008,China.2.Jiangsu Key Laboratory of Resources and Environmental Information Engineering,Xuzhou 221008,China

摘要: 文章比较和分析了几种矿井巷道三维建模技术,提出了一种基于ArcGIS MultiPatch 3D数据结构的矿井巷道三维建模方法,即在C#开发环境下,结合巷道自身的特点,在ArcGIS Engine平台上进行二次开发,实现了矿井巷道的三维自动建模。该方法为矿井巷道三维信息系统的建立提供了新的解决方案。
- 矿井巷道 /
- 三维自动建模 /
- Multi Patch /
- ArcGIS Engine
Abstract: The paper compared and analyzed 3D modeling technologies of mine laneway,put forward a 3D modeling method of mine laneway based on MultiPatch 3D data structure in ArcGIS.Considering characteristics of mine laneway,the method realized 3D automatic modeling of mine laneway based on secondary development on ArcGIS Engine platform under the C# developing environment.The method provides a new solution for establishment of 3D mine laneway information system.
- mine laneway /
- 3D automatic modeling /
- MultiPatch /
- ArcGIS Engine
