基于相控投切技术的无功补偿系统设计

Design of Reactive Power Compensation System Based on Phase-controlled Switching Technology

  • 摘要: 针对传统的无功补偿方式会造成过电压、过电流而严重危害电网电能质量的问题,提出一种基于相控投切技术的无功补偿系统设计方案;介绍了相控投切技术原理、系统整体结构设计及软件设计;针对系统的两大关键问题,提出一种电压过零点信号提取方法和利用BP神经网络算法进行分合闸时间预测的方法。该系统在电压、电流信号过零点处投切电容器组,实现了对电网功率的无功补偿。测试结果表明,该系统能够准确、实时地补偿电网所需的无功功率,提高电网功率因数。



    Abstract: In allusion to the problem that traditional reactive compensation method could cause over-voltage and over-current which seriously disserves power quality, the paper proposed a design scheme of reactive power compensation system based on phase-controlled switching technology, and introduced principle of phase-controlled switching technology, overall structural design and software design of the system. For two key problems of the system, the paper proposed an extraction method of voltage zero-crossing signal and a method of using BP neural network algorithm to predict time of switching off or switching on. The system switches capacity while the voltage or current signal at zero crossing time, and realizes reactive power compensation of the grid. The tests showed that the system can accurately and real-timely compensate reactive power required by grid and improve power factor.



/
