基于AutoCAD的矿井采区供电设计系统

Power Supply Design System of Mining Area Based on AutoCAD

  • 摘要: 针对传统的矿井采区供电设计系统存在绘图与计算分离、整定计算滞后于现场供电系统变化的问题,提出了一种基于AutoCAD的矿井采区供电设计系统的设计方案。该系统在AutoCAD平台上利用其内嵌的VBA进行二次开发,通过编写程序扩展AutoCAD的功能,将供电设计的绘图、计算、文档管理等工作集中在一个软件下实现。实际应用表明,该系统具有交互性好、操作方便、可靠性高等特点。



    Abstract: In view of problems of separation of drawing and calculation, setting calculation lagging behind change of field power system existed in traditional power supply design system of mining area, the paper proposed a design scheme of power supply design system of mining area based on AutoCAD. The system uses embedded VBA of AutoCAD platform to make secondary development, and compiles program to extend functions of AutoCAD to realize integration of drawing, calculation and file management of power supply design by one software. The actual application showed that the system has characteristics of good interaction, convenient operation and high reliability.



/
