Implementation of TFT-LCD Display System with High Gray Levels
-
摘要: 提出了一种以FPGA为核心控制器的高灰度级TFT-LCD显示系统的设计方案。该系统采用幅值-帧速率控制调制-空间混合灰度调制方法，首先将10 bit的R、G、B信号分割成高8 bit数据和低2 bit数据，低2 bit数据经过空间处理后平均分到4个相邻的8 bit数据上，然后把这8 bit数据继续分割成高6 bit数据和低2 bit数据，其中高6 bit数据用于幅值调制，低2 bit数据用于帧速率控制调制，从而实现1 024个灰度等级显示。试验结果表明，该系统具有良好的显示效果和较高的显示灰度等级。Abstract: The paper proposed a design scheme of TFT-LCD display system with high gray levels which takes FPGA as core controller. The system uses mixed gray modulation method of amplitude-FRC-space, which segments 10 bit R, G, B signal into high 8 bit data and low 2 bit data, and the low 2 bit data processed by space process are assigned to four adjacent 8 bit data equally, then the 8 bit data are segmented into high 6 bit data and low 2 bit data, and the high 6 bit data are used for amplitude modulation, the low 2 bit data are used for FRC, so as to realize 1 024 gray levels display. The test result showed that the system has good display effect with high display gray levels.
-
