基于以太网的煤矿排水综合自动化系统

Integrated Automation System for Drainage of Coal Mine Based on Ethernet

  • 摘要: 针对国内煤矿排水系统中现有的继电器控制方式效率低、工人劳动强度大、误操作较多等问题,文章介绍了一种煤矿排水综合自动化系统。该系统结合计算机技术、工业以太网技术以及PLC控制技术,采用分层结构设计方法,并采用VC++和PLC组态软件设计系统的主站和分站软件,不仅实现了自动恒水位排水,而且可以集中监测排水系统的运行工况,从而提高了煤矿排水系统的安全性和可靠性。实际运行结果表明,该系统性能稳定可靠,控制精度较高,可满足煤矿安全生产的要求。



    Abstract: Aiming at the problems such as low efficiency,huge labor intensity,more misoperations of existing relay control way in drainage system of domestic coal mine,the paper introduced an integrated automation system for drainage of coal mine.The system combines with technologies of computer,industrial Ethernet and PLC control,adopts layered structure design method,and adopts (VC++) and configuration software of PLC to design software of main station and substation of the system.It not only realizes automatic drainage with constant water level but also can monitor running conditions of the drainage system centrally, so as to improve security and reliability of the drainage system of coal mine.The actual running result showed the system has stable and reliable performance and higher control precision,which can meet requirements of safe production of coal mine.



/
