矿用直流不间断电源的设计

详细信息

Design of Mine-used DC UPS

1.
Branch of Measurement and Control of Chongqing Research Institute of China Coal Technology and Engineering Group Corporation, Chongqing 400039, China. 2.Testing Center of Chongqing Research Institut

摘要: 设计了一种煤矿井下交换机用直流不间断电源。该不间断电源采用MAX713电源管理芯片对镍镉电池进行智能充电；采用MSP430F147单片机作为微处理器，利用外部中断方式监测矿用交流电的工作状态，当发现矿用交流电不能正常供电时对电路进行切换，启动镍镉电池供电，从而保证交换机持续工作。测试结果表明，该不间断电源具有一定的实用性。
- 矿用交换机 /
- 直流不间断电源 /
- 镍镉电池 /
- 充电 /
- MSP430F147 /
- MAX713
Abstract: A DC UPS used in underground exchanger was designed. The UPS uses MAX713 to make intelligent charging for Ni-Cd battery; it takes MSP430F147 as microprocessor, uses external interruption mode to monitor working state of mine-used AC, and it can switchover to start Ni-Cd battery supply when mine-used AC has fault, so as to ensure continuous work of exchanger. The test result showed that the UPS has certain practicality.
- mine-used exchanger, DC UPS, Ni-Cd battery, charging, MSP430F147, MAX713
