基于LabVIEW的微震实时监测系统

详细信息

Real-time Monitoring System for Microseism Based on LabVIEW

State Key Laboratory of Coal Resources and Safe Mining of CUMT., Xuzhou 221008, China. 2.School of Safety Engineering of CUMT., Xuzhou 221116, China

摘要: 针对锡铁山铅锌矿深部地压活动频繁的现状，提出了一种基于LabVIEW的微震实时监测系统的设计方案。该系统采用三分量检波器检测微震信号，通过前置放大电路、滤波电路、NI CRIO-9014嵌入式实时控制器与NI 9201采集模块将信号送入工控机及LabVIEW软件平台进行处理，从而实现微震实时监测及定位功能。实际应用表明，该系统的实时性和准确性满足设计要求，具有一定的可行性。
- 深部地压 /
- 微震监测 /
- LabVIEW /
- 三分量检波器 /
- P波初至到时定位
Abstract: In view of present situation of frequent activities of deep ground pressure in Lead-zinc Mine of Xitieshan, the paper proposed a design scheme of real-time monitoring system for microseism based on LabVIEW. The system uses three-component geophone to detect microseism signal and transmit the signal to industrial computer and LabVIEW software platform to make process through preamplifier circuit, filtering circuit, NI CRIO-9014 and NI 9201, so as to realize real-time monitoring and location function for microseism. The actual application showed that real-time performance and accuracy of the system meet with design requirements and the system has certain feasibility.
- deep ground pressure, microseism monitoring, LabVIEW, three-component geophone, first arrival-time location of P wave
