煤矿机电设备监测系统的设计

Design of Monitoring System for Electromechanical Equipments of Coal Mine

  • 摘要: 为了实时了解煤矿主要机电设备的运行情况,提出了一种煤矿机电设备监测系统的设计方案。该系统采用温度传感器、压力传感器、电量采集盒采集井下通风机、提升机等主要机电设备的运行状态数据,将数据统一传送到监测分站,监测分站通过RS485总线与地面监测中心的上位机通信,从而实现对煤矿井下机电设备的远程监测功能。长时间的性能测试结果表明,该系统运行状况良好。



    Abstract: In order to know running state of main electromechanical equipments of coal mine, the paper proposed a design scheme of monitoring system for electromechanical equipments of coal mine. The system uses temperature sensor, pressure sensor and electric acquisition box to collect running state data of main electromechanical equipments of coal mine such as fan and hoist, and sends the data to monitoring substations which communicate with upper computer of surface monitoring center through RS485 bus, so as to realize remote monitoring function for underground electromechanical equipments. Long-time performance test result showed that the system has perfect running state.



/
