3D Visualization Platform of Mine Based on 3D GIS
-
摘要: 针对2D GIS煤矿信息管理系统存在的问题,提出了一种基于3D GIS的矿井三维可视化平台的设计方案;详细介绍了该平台的整体结构、功能模块的作用及应用效果。实际应用表明,该平台实现了各类安全监测数据之间的融合和可视化分析,可对煤矿安全隐患进行快速、准确的预警、预报。Abstract: In view of problems existed in 2D GIS information management system of coal mine, the paper proposed a design scheme of 3D visualization platform of mine based on 3D GIS. It introduced whole structure, functions of function modules and application effect of the platform. The actual application showed that the platform realizes fusion and visualization analysis of kinds of safety monitoring data and can make quick and accurate warning and forecasting for hidden danger of coal mine.
-
