一种高性能低噪声数据采集卡的设计

Design of a Data Collection Card with High Performance and Low Noise

  • 摘要: 针对目前国内USB接口的数据采集产品存在精度低、采样率低、数据传输速率低的问题,设计了一种高性能低噪声数据采集卡。该数据采集卡采用高速差分放大器AD8132进行前置放大;采用CPLD和SRAM构成大容量FIFO;采用USB2.0总线技术进行数据传输;采用独立时钟为CPLD和AD转换器提供精确的同步时钟信号,从而降低时钟相位噪声;采用VC++设计上位机应用程序,用于分析和处理数据。测试结果表明,该数据采集卡具有噪声低、传输速率快、精度高等优点。



    Abstract: In view of problems of low precision, low sampling rate and low data transmission rate existed in current data collection products based on USB interface in China, a data collection card with high performance and low noise was designed. The card uses high-speed differential amplifier AD8132 to make preamplifier; uses CPLD and SRAM to compose large capacity FIFO; uses USB2.0 bus technology to transmit data; uses independent clock to provide accurate synchronous clock signal for CPLD and AD converter to reduce clock phase noise; uses VC++ to design application program of upper computer to realize data analysis and processing. The test result showed that the card has advantages of low noise, rapid transmission rate and high precision.



/
