煤矿主通风机监控系统的实现

Implementation of Monitoring and Control System of Coal Mine Main Ventilator

  • 摘要: 以某矿井主通风机监控为例,提出了一种基于PLC、电力监视器和组态软件的主通风机监控系统的设计方案,介绍了该系统的硬件配置、实施方案和主要功能。该系统实现了对煤矿主通风机各个环节的监控功能。实际应用表明,该系统安全可靠、控制方便、可扩展强。



    Abstract: Taking monitoring and control of a coal mine main ventilator as an example, the paper put forward a design scheme of monitoring and control system of main ventilator based on PLC, power monitor and configuration software, and introduced hardware configuration, implementation scheme and main functions of the system. The system realizes monitoring and control fuction of each link of coal mine main ventilator. The practical application showed that the control system is reliable, easy in control and strong in extend.



/
