煤矿供电系统雷击情况的仿真研究

Simulation Research of Lightning of Mine Power Supply System

  • 摘要: 选取矿区常用的110 kV级的输电线路作为仿真研究对象,采用ATP-EMTP电磁暂态分析软件建立了雷击输电线路的数学模型,通过改变杆塔接地电阻值的大小以及安装与不安装线路避雷器对雷击过程的影响进行了仿真分析。仿真结果表明,雷击杆塔顶时,输电线路杆塔接地电阻值越大,输电线路的耐雷水平会降低;输电线路安装避雷器可有效降低输电线路过电压。



    Abstract: The paper selected 110 kV transmission line of mine area for simulation research object and used ATP-EMTP electromagnetic transient analysis software to establish mathematical model of transmission line struck by lightning. It made simulation analysis for influence of lightning process by changing grounded resistance value of tower and installing or not installing lightning arrester. The simulation result showed that when lightning strikes top of tower, the grounded resistance value of tower is bigger, the lightning withstand level of transmission line is lower; installing lightning arrester in transmission line can reduce overvoltage effectively.



/
