永磁同步电动机矢量控制系统的仿真研究

董圣英

董圣英. 永磁同步电动机矢量控制系统的仿真研究[J]. 工矿自动化, 2010, 36(8): 73-77.
引用本文: 董圣英. 永磁同步电动机矢量控制系统的仿真研究[J]. 工矿自动化, 2010, 36(8): 73-77.
DONG Sheng-ying~. Simulation Research of Vector Control System of Permanent Magnet Synchronous Motor[J]. Journal of Mine Automation, 2010, 36(8): 73-77.
Citation: DONG Sheng-ying~. Simulation Research of Vector Control System of Permanent Magnet Synchronous Motor[J]. Journal of Mine Automation, 2010, 36(8): 73-77.

永磁同步电动机矢量控制系统的仿真研究

详细信息
  • 中图分类号: TM341

Simulation Research of Vector Control System of Permanent Magnet Synchronous Motor

  • 摘要: 分析了电压空间矢量脉宽调制原理和算法,建立了一种基于SVPWM的永磁同步电动机矢量控制系统的仿真模型,给出了各子模块的具体设计方案;对积分斜率法产生三角波的方法进行了改进。仿真和实验结果证明了所建模型的正确性和系统的可行性,为分析和设计PMSM控制系统提供了有效的手段和工具。
    Abstract: The paper analyzed the principle and algorithm of SVPWM,built a simulation model of vector control system of PMSM based on SVPWM,and gave concrete design scheme of each sub-module of the model.It also modified integral-slop method for producing triangle carrier.The simulation and experimental results showed that the model was correct and the system was feasible,which offers a valid mean and tool for analyzing and designing a control system of PMSM.
