多通道微震信号采集系统设计

基金项目:

中央高校基本科研业务费专项项目（ZY20160104）

中国地震局地震科技星火计划项目(XH14072)

详细信息

.Design of acquisition system of multi-channel microseismic signal

Vibration Precision Measurement Technology and Instruments Key Laboratory， Institute of Disaster Prevention Science and Technology， Langfang 065200, China

摘要: 针对现有矿山微震信号采集系统存在价格昂贵且通用性不强等问题，设计了一种多通道微震信号采集系统。该系统采用地震计拾取微震信号，利用采集电路实现对微震信号的放大、数模转换及数字滤波，利用STM32将滤波后的信号通过USART实时发送给上位机进行分析处理。测试结果表明，该系统可以准确采集、记录地震计拾取的3个通道的微震信号，稳定性好、可靠性高、成本低。
- 矿山微震信号 /
- 地震计 /
- 数据采集 /
- 信号监测 /
- STM32
Abstract: In view of problems of high cost and low universality existed in current acquisition systems of mine microseismic signal, an acquisition system of multi-channel microseismic signal was designed. The system adopts seismometer to collect microseismic signals, uses acquisition circuit to implement amplification for microseismic signals, analog-to-digital conversion and digital filter, and uses STM32 to real-timely send filtered signals to PC for analysis by USART. The test results show that the system can accurately collect and record 3-channel microseismic signals collected by seismometer with good stability, high reliability and low cost.
- mine microseismic signal /
- seismometer /
- data acquisition /
- signal monitoring /
- STM32
