基于虚拟现实技术的煤矿全液压钻机培训系统

Training system for coal mine full-hydraulic drilling rig based on virtual reality technology

  • 摘要: 针对传统煤矿全液压钻机培训效果不理想的问题,开发了一种基于虚拟现实技术的煤矿全液压钻机培训系统。该系统由下位机和上位机组成,二者之间通过FX2N系列PLC编程口实现通信;下位机利用PLC完成钻机虚拟操控台控制指令的采集和处理;上位机应用Quest3D虚拟软件实现虚拟钻机和场景搭建、关键零部件虚拟拆装和虚拟钻机动作编程。该系统人机交互性能良好,操作简单易懂,缩短了培训周期,降低了培训成本。



    Abstract: In view of problem of unsatisfactory effect of traditional training for coal mine full-hydraulic drilling rig, a training system for coal mine full-hydraulic drilling rig based on virtual reality technology was developed. The system is consisted of lower computer and upper computer, and communication between the lower computer and the upper computer is realized through FX2N series PLC programming interface. The lower computer uses PLC to collect and process control instruction of drilling rig virtual console. The upper computer applies Quest3D virtual software to realize virtual drilling rig and scene setting, key parts virtual disassembly and virtual drilling rig operation programming. The system shortens training period and reduces training cost with good human-computer interaction performance and simple operation.



/
