运输小车在螺旋钻杆翼片焊接工作站中的应用

Application of travelling bogie ivane n welding station of spiral drill pipe

  • 摘要: 针对螺旋钻杆翼片焊接工作站的钻杆运输依靠人工进行的问题,将运输小车应用到螺旋钻杆翼片焊接工作站中,实现了钻杆在上下料工位和2个焊接工位间的运输。运输小车控制程序采用PLC-FX3U编程,实现了运输小车与焊接工作站的联合协调工作。应用结果表明,使用运输小车后,整个钻杆运输流程用时缩短了近一半,效率提高了约43%。



    Abstract: In view of problem that drill pipe transportation depends on manual operation in vane welding process of spiral drill pipe, travelling bogie was applied to vane welding station of spiral drill pipe, which realized transportation of drill pipes between loading and unloading stations and two welding stations. Control program of the travelling bogie was programmed by PLC-FX3U to achieve joint coordination between the travelling bogie and welding station. Application results show that transport time of the entire drill pipe transport process was shortened by nearly half and the efficiency was increased by about 43% after use of the travelling bogie.



/
