三线圈无线电能传输系统耦合机理研究

刘溯奇; 谭建平; 文学

doi:10.13272/j.issn.1671-251x.2017.07.013

三线圈无线电能传输系统耦合机理研究

刘溯奇^{1, 2},
谭建平^{1, 2},
文学^{1, 2}

1.
高性能复杂制造国家重点实验室, 湖南长沙410083
2.
中南大学机电工程学院，湖南长沙410083

基金项目:

国家重点基础研究发展计划(973计划)资助项目(2014CB049405)

详细信息

中图分类号: TD655.3
计量
- 文章访问数: 83
- HTML全文浏览量: 12
- PDF下载量: 12
出版历程
- 刊出日期: 2017-07-09

Research on coupling mechanism of three-coil wireless power transmission system

LIU Suqi^{1, 2},
TAN Jianping^{1, 2},
WEN Xue^{1, 2}

1.
State Key Laboratory of High Performance Complex Manufacturing, Changsha 410083, China
2.
School of Mechanical and Electrical Engineering, Central South University, Changsha 410083,China

摘要

摘要: 针对三线圈无线电能传输系统中继线圈位置变化会改变系统传输性能的实际问题，研究了三线圈无线电能传输系统耦合机理；通过建立三线圈无线电能传输系统等效电路模型，推导出系统输出功率增益和传输效率基本特性公式，分析了系统输出功率增益、传输效率与特性参数的相互作用机理，得出了系统输出功率增益、传输效率各自的规律；设计开发了无线电能传输实验系统，验证了理论分析的正确性。
- 无线电能传输 /
- 三线圈 /
- 中继线圈 /
- 耦合机理 /
- 输出功率增益 /
- 传输效率
Abstract: In view of problems that transmission performance of three-coil wireless power transmission system would change with moving of relay coil, coupling mechanism of three-coil wireless power transmission system was researched. An equivalent circuit model of the wireless power transmission system was built which is based on three-coil structure, and basic characteristic formula of output power gain and transmission efficiency were deduced. Interaction mechanism of the output power gain, transmission efficiency and characteristic parameters were analyzed, and laws of the output power gain and transmission efficiency of the system were obtained. The wireless power transmission experiment system was developed which verifies correctness of the theoretical analysis.
- wireless power transmission /
- three-coil /
- relay coil /
- coupling mechanism /
- output power gain /
- transmission efficiency
