一种新型矿用高压保护器综合测试台设计

Design of a new type of integrated test bench for mine-used high-voltage protector

  • 摘要: 设计了一种新型矿用高压保护器综合测试台,介绍了该测试台的总体结构及软、硬件设计方案。该测试台以S7-300系列PLC为控制器,可以产生短路、过流、欠压、过压、零序过压、零序过流等故障信号,并将故障信息、试验项目及相关硬件运行状态显示在上位机监控界面上,从而快速检测高压保护器的性能。以ZBT-11高压保护器电流保护功能测试为例进行了测试台功能检测,结果表明该测试台能够快速、准确地检测出高压保护器故障。实际应用验证了该测试台效果良好。



    Abstract: A new type of integrated test bench for mine-used high-voltage protector was designed. The overall structure and design schemes of software and hardware of the test bench were introduced. Fault signals are provided by the test bench which takes S7-300 PLC as a controller such as short-circuit current, over current, under-voltage, over-voltage, zero sequence over-voltage, zero sequence over-current and so on. Fault information, test items and relative hardware running status are displayed on monitoring interface of upper computer so as to detect performance of high-voltage protector quickly. Function of the test bench was tested by taking current protection function test of ZBT-11 type high-voltage protector as an example. The test result shows that the test bench can detect faults of high-voltage protector quickly and accurately. The practical application verifies perfect effect of the test bench.



/
