井下液压支架压力在线监测系统设计

Design of online pressure monitoring system of underground hydraulic support

  • 摘要: 针对现有煤矿井下液压支架压力监测系统存在布线困难、组网规模小、传输距离短等问题,采用WaveMesh无线自组网技术,设计了一种井下液压支架压力在线监测系统。该系统通过无线压力传感器采集液压支架的压力数据,压力数据以无线方式传送给无线监测分站,并由无线监测分站通过RS485总线与光纤环网相连上传至地面监测主机。实际应用表明,该系统运行稳定、可靠,可实时、精确监测井下液压支架的压力变化。



    Abstract: For problems of complex wiring, small network scale and short transmission distance of existing pressure monitoring system of coal mine underground hydraulic support, an online pressure monitoring system of underground hydraulic support was designed by use of WaveMesh wireless ad hoc network technology. The system collects pressure data of hydraulic support through wireless pressure sensor. Wireless monitoring substation receives the pressure data wirelessly and sends it to ground monitoring host through RS485 bus and optical fiber ring network. The application shows that the system runs stably and reliably, which can realize real-time and accurate monitoring of underground hydraulic support pressure.



/
