基于nRF24L01和STM32的定量装车站无线控制系统

Wireless control system of quantitative loading station based on nRF24L01 and STM32

  • 摘要: 针对常规的自动化快速定量装车站操作人员在装车时存在视觉盲区的问题,设计了一种基于nRF24L01和STM32的定量装车站无线控制系统。该系统通过无线手持控制终端将控制指令发送到装车站接收端,实现了对装车站装载情况的控制。试验结果表明,在有遮挡物的情况下,定量装车站无线控制系统可以实现20 m范围内数据的有效传输,从而可对装车站的装载情况进行实时控制。



    Abstract: In view of problem that operators of conventional automatic rapid and quantitative loading station have visual blind spot during loading process, a wireless control system of quantitative loading station based on nRF24L01 and STM32 was designed. The system uses wireless handheld terminal to send control commands to loading station receiver, and achieves control of loading conditions of the loading station. The test results show that the system can achieve effective data transmission within the range of 20 m, so as to realize real-time control of loading conditions of the loading station.



/
