基于X射线的钢丝绳芯无损探伤系统研究

Research of non destructive detection system of steel rope core based on X-ray

  • 摘要: 设计了一种基于X射线的钢丝绳芯无损探伤系统。该系统利用X射线的良好穿透性检测钢丝绳芯输送带中的钢丝绳缺陷,采用光纤将现场采集的图像信息传输到远程上位机中进行分析处理,实现了钢丝绳芯缺陷图像的在线智能识别和分析等功能。原理样机测试结果表明,该系统能够检测出切断、凿穿、接头抽动、撕裂等钢丝绳缺陷,在保证X射线安全工作的前提下,提高了检测效率和准确性。



    Abstract: The paper designed a kind of non destructive detection system of steel rope core based on X-ray. The system takes advantage of good penetrability of X-ray to inspect defects of steel wire rope in belts, uses optical fiber to transmit images information collected on site to remote host computer for analysis and processing, and realizes functions of online intelligent identification and analysis of defect images of steel rope core. Prototype test results show that the system can inspect defects of cut through, puncture, joint twitching, tearing and so on, which improves inspection efficiency and accuracy under the premise of ensuring safety working of X-ray.



/
