蒸发式冷凝器冷却水节能自动控制系统设计

Design of automatic energy-saving control system of cooling water of evaporative condenser

  • 摘要: 针对矿井冻结法施工中蒸发式冷凝器冷却水系统均采用人工控制的现状,为了简化工序、提高工作效率,设计了一种蒸发式冷凝器冷却水节能自动控制系统。该系统采用浮球液位控制器将蒸发式冷凝器冷却水水位转换为电信号,通过接触器、中间继电器等低压电器控制循环泵通断,实现蒸发式冷凝器冷却水自动循环;采用温度控制器,通过检测冷却水温度控制总蓄水箱中冷却塔开停及系统运行模式,确保冻结法施工制冷系统安全、高效、节能运行。



    Abstract: For current status that cooling water system of evaporative condenser uses manual control in mine construction utilizing freezing method, an automatic energy-saving control system of cooling water of evaporative condenser was designed in order to simplify process and improve efficiency. In the system, cooling water level of evaporative condenser is converted into electrical signal by use of ball float level controller for controlling circulating pump through contactors, intermediate relays and other low-voltage electrical apparatus, so as to realize automatic circulation of cooling water of evaporative condenser. Cooling tower in total water storage tank and operation mode of the system are controlled by use of temperature controller through detecting temperature of cooling water, so as to ensure safe, high-efficient and energy-saving operation of refrigeration system in construction utilizing freezing method.



/
